MODULE // FRAMING, ASPECT RATIOS & CAPTIONS

Delivery: Fit the frame and the words

A finely paced edit can still fail in the final export pass if the subject's hands are cropped off the edge of a vertical screen or if burned-in captions sit directly behind a platform's translucent caption description bar. Treating aspect ratios and subtitles as deliberate compositional choices—rather than automated export presets—protects your story on any screen size.

Close-up of an editing monitor showing two-line high-contrast captions positioned inside a 9:16 vertical safe-zone grid

1. Choosing and reframing aspect ratios without motion sickness

Visible problem in the clip: A horizontal 16:9 interview or demonstration was converted to 9:16 using an AI auto-reframe filter, causing the vertical frame to drift left and right every time the speaker nods or gestures.

Purpose of the edit: A camera frame should feel anchored unless the subject actually walks across the room. When repurposing horizontal 4K (`3840×2160`) footage into a vertical `1080×1920` sequence, you have generous horizontal pixel headroom, so lock the X-axis position per cut rather than letting software chase micro-movements.

Aspect Ratio Pixel Dimensions Primary Use Case Safe Margin Clearance (1080px base)
9:16 Vertical 1080 × 1920 px Full-screen mobile feeds (Reels, Shorts, TikTok) Top: 220px | Bottom: 380px | Right: 140px
4:5 Portrait 1080 × 1350 px In-feed mobile scroll and portfolio feeds Top: 90px | Bottom: 120px | Sides: 70px
1:1 Square 1080 × 1080 px Embedded web documentation and grid previews Uniform 80px inset border
16:9 Widescreen 1920 × 1080 px Desktop players and horizontal archive masters 10% Action Safe / 20% Title Safe

2. Designing captions for effortless reading speed

Visible problem in the clip: Single-word "pop-up" captions flash at 240 words per minute in neon colors, forcing the viewer to stare at the text like a strobe light instead of watching the visual demonstration above it.

Purpose of the edit: Good captions allow a viewer in a quiet train carriage—or a viewer learning in a second language—to absorb the spoken phrase in a single peripheral glance and immediately return their eyes to the action.

  1. Break lines by linguistic phrase, not character limit

    Keep between 3 and 7 words on screen at a time (roughly 1.2 to 2.2 seconds per card). Never leave prepositions ("of", "to", "with") dangling at the end of Line 1 while their object starts on Line 2.

  2. Ensure luminance contrast against bright footage

    White text disappears the moment a presenter wears a white shirt or steps in front of a window. Add a subtle dark semi-opaque background pill (`rgba(15, 25, 22, 0.75)` with `12px` corner radius) or a crisp dark outer stroke plus tight drop shadow.

  3. Lead the spoken audio by 1 to 2 frames

    When a subtitle card snaps onto the screen one or two frames before the speaker voices the first syllable of that phrase, the viewer perceives the text as perfectly responsive rather than lagging behind the mouth movement.

3. The Pre-Export Technical Checklist

Before queuing your render, run a 15-second technical verification pass across your sequence settings:
